Self Adhesive Sticker Automatic Round Bottle Labeling Machine With Big Capaciy
  • Self Adhesive Sticker Automatic Round Bottle Labeling Machine With Big Capaciy
  • Self Adhesive Sticker Automatic Round Bottle Labeling Machine With Big Capaciy
  • Self Adhesive Sticker Automatic Round Bottle Labeling Machine With Big Capaciy

Self Adhesive Sticker Automatic Round Bottle Labeling Machine With Big Capaciy

Place of Origin China
Brand Name LTPM China
Certification CE, GMP
Model Number MT-200
Product Details
Usage:
Round Bottle
Label:
Single Side Label
Capaciy:
200bottle/min
Power:
1.5Kw
Power Supply:
220V 50hz Single Phase (customized)
Bacth Number:
Ribon Coding Machine Is Available
Bottle Height:
15-200mm
Accuracy:
1mm
High Light:

bottle labeler machine

,

self adhesive labelling machine

Payment & Shipping Terms
Minimum Order Quantity
1set
Price
Negotiation
Packaging Details
Export standard wooden case
Delivery Time
25days
Payment Terms
L/C, T/T
Supply Ability
25sets/month
Product Description

Product Introduction

1 Heavy-duty construction utilizes oversized drive components combined with an aluminum and stainless steel base frame for years of dependable service.

2 Various product infeed systems are available that provide precise product spacing and orientation. It can be used stand alone or integrated in-line and matching filling equipment speeds.

3 Advanced high torque micro-stepping driven applicators include ratio-offset and speed-following capability for accurate and

reliable application of a wide variety of label materials.

4 Designed for the application of front and/or back panel labels with the capability to label containers that are round, square,

oval or rectangular.

Self Adhesive Sticker Automatic Round Bottle Labeling Machine With Big Capaciy 0

Device Structure

1.Head motherboard

Using 20mm thick aluminum plate, the overall planing mill treatment to ensure surface flatness. Anodized aluminum surface

treatment, sandblasting process to ensure that the hardness and appearance. All guides are used to send standard sink-hole process

to ensure that no verticality with guides to ensure delivery subject stability. Head motherboard using the most advanced CNC

machining centers to ensure the accuracy of every size.

2.Label Feeder

Send scaler 5-axis positioning mechanism, which greatly ensure stability during delivery standard. Subscript label feed roller 2 /3 near the contact area to avoid a great slip the label and the roller, to improve the accuracy of delivery targets. Send and receive standard synchronous standard skid control, to avoid the label pulled off .

3.Touch Screen

Taiwan Winview touch screen with high-quality large touch screen, interactive, easy to operate And outside touch screen plus a protective cover .

4.Cabinet

Chassis is made of 304 stainless steel fully sealed structure, effectively prevent dust and water from entering.

5.Base

The bottom of the nose fully sealed structure to avoid the risk of the occurrence of.

6.Frequency converter

Using the French Schneider inverter, stable performance.

7.PLC

Japan's Mitsubishi Electric PLC and quality performance and stability.



Working principle

The bottles that need to be labelled are transmitted through the bottle feeding track, and the bottles are equidistantly separated by the bottle distance adjustment mechanism. The photoelectric sensor senses the passing bottles and sends a signal. The transmission system gets the signal to start, and the label is sent. The tension of the paper tape is coded by the coding machine, and the photoelectric sensor for positioning paper is positioned according to the length of the paper, so that the length of the paper drawn by the paper is equal. Under the action of the labelling component and the labelling component, The label paper is automatically peeled off, and it is evenly attached to the required position of the bottle to complete the entire labelling process.



Main Features

(1) Strong compatibility, suitable for various round objects;

(2) Tension design is used for marking, which can ensure the quality of coding, and can also accurately control the length of the label paper and the uniformity of the starting mark. (3) Adopt pre-labelling system, stable label output, good labelling flatness and high position accuracy;

(4) Rolling label paper adopts different methods for different bottle types to ensure the quality of labelling;



Main Technical Data:
Driver: Stepping motor
Operation: Right or left
Poster speed: 0-200 PCS/min

Packaging Range:



20 - 100mm diameter

Height 25-350mm

Label size width 10-150mm length 15-200mm
Labeling precision + 1mm (depending on the bottle degree, perpendicular round)
Maximum diameter volume label: dia.300mm
Coil diameter: Dia. 75mm label
Weight: 200kg
Power supply: AC220V 0.5Kw 60HZ
Overall Size: 2000X1300X1500
Ribbon Coding machine: HP 260Q
