BHP-240Z Horizontal Automated Packaging Machine For Doypack With Zipper Function
Function:
The machine can automatic finish bag forming, filling, easy tear notch making, sealing, finished bag
discharged. Reclosable zipper, spout and Round corner punching are optional.
Machine Feature:
1. Automatically check pouch open status, it will not fill and seal when pouch is not opened fully. It avoids the wasting of pouch
and raw material and save cost.
2. Machine working speed can be adjusted continuously with frequency converter
3. SIEMENS PLC adopted, the control system is easy to operated with friendly HMI interface.
4. Machine will alarm when the air pressure is abnormal and stop working with overload protect and safety device.
5. Machine can work with dual-fill, filling with two types of material, such as solid and liquid, liquid and liquid.
6. Machine can work with pouch width range from70-150mm, 100-200mm, 200-300mm by adjusting the width of clips.
7. Adopting advanced bearing, where no need to add oil and less pollution for product.
8. All the product and pouch contact parts are made with stainless steel or the material according with the food hygienic
requirements, guarantee hygiene and security of the food.
9. Rotary packing machine can work with different filler to pack solid, powder and liquid.
10. With pre-made pouch, the pattern and sealing on the pouch is perfect. The finished product looks advanced.
11. Machine can work with complex film, PE, PP material premade pouch and paper bag
Technical Specifications:
| Working position | eight-working position |
| Pouch material | Laminated film PE,PP |
| Pouch pattern | stand-up&zipper pouch |
| Pouch size | W:100-210mm L:100-350mm |
| Filling Scope | 10-5000g( The screw attachment is to be changed) |
|
Weight Accuracy
|
Package weight ≤ 100g, with an error≤±2% 100 — 500g,with an error≤±1% ≥500G error≤±0.5% |
| Speed | 10-45pouches/min(The speed depends on the product status and flling weight)) |
| Voltage | 380V 3phase 50HZ/60HZ |
| Total power | 8.5KW |
| Compress air | 0.6m3/min(supply by user) |
Multi-head weigher
Ten-head, fourteen-head, sixteen-head, and twenty-head electronic scales can be customized. The product is accurately weighed to
the required weight through an electronic scale.
Platform
Made of 304 stainless steel, it is convenient to check whether the multi-head scale is operating normally and protect the
stability of the operation of the machine and the weighing device.
Doypack machine
It adopts fully automatic packaging, 6 stations work at the same time, automatic bag adjustment system, packaging different products, fast switching of bag width, and convenient operation.
Applications:
It can be used to pack powder product such as milk powder,flour, cosmetic powder,etc up to 1000ml,
