Vacuum 4 Heads 700kg Liquid Filling Machine Perfume Bottle 100ml
  • Vacuum 4 Heads 700kg Liquid Filling Machine Perfume Bottle 100ml
  • Vacuum 4 Heads 700kg Liquid Filling Machine Perfume Bottle 100ml
  • Vacuum 4 Heads 700kg Liquid Filling Machine Perfume Bottle 100ml

Vacuum 4 Heads 700kg Liquid Filling Machine Perfume Bottle 100ml

Place of Origin China
Brand Name LEADTOP
Certification CE certification
Model Number RotaFill-Series
Product Details
Model:
RotaFill-Series
Range:
5ml-100ml
Speed:
30-40bottles/minute
Measurement Precision:
±1%
Net Weight:
700kg
Contour Sizes:
2400×1640×1580mm
Certification:
CE Certificate
Weight:
Depend On Size
High Light:

100ml Perfume Liquid Filling Machine

,

700kg Liquid Filling Machine

,

100ml perfume bottle filling machine

Payment & Shipping Terms
Minimum Order Quantity
1 set
Price
discuss personally
Packaging Details
wooden box
Delivery Time
25days
Payment Terms
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability
25 days/month
Product Description

Description:

The vacuum liquid filling machine can prevent the fragrance of liquid from spreading,this is especially good for perfume filling.It is full automatic and can work with automatic capping machine to realize automated production.Multiple filling nozzles can be customized according to production needs.



Feature
1.Machine uses plunger type metering pump filling, high precision; The structure of pump adopts fast disassembled mechanism, easy to clean and disinfect.

2.PLC control system, color touch screen display, machine has function of counting automatically.

3.The filling nozzle was equipped with drip-proof device.

4.When filling liquid, the filling nozzles dive into the bottom of bottles, rising slowly, it can effectively prevent bubbles.

5.Main electrical elements adopt foreign well-known brand s .

6.Machine shell is made of 304 stainless steel, meets GMP standards.



Technical parameters:

Capacity
2500BPH (500ml)
Bottle Height
150~310mm
Bottle Diameter
50~96mm(diameter)
Bottle Type
PET bottle
Cap
HDPE Cap
Washing Head
8
Washing Capacity
1000kgs/hour
Washing Pressure
0.2-0.4Mpa
Filling Heads
8
Capping Heads
3
Rated Voltage
220V/380V,50/60HZ, 3 phase
Main Motor Power
1.5kw
Total Motor Power
3kw
Overall dimension
2000*1800*2100mm
Weight
1800Kg







Machine Details:





Vacuum 4 Heads 700kg Liquid Filling Machine Perfume Bottle 100ml 0

Application

Vacuum 4 Heads 700kg Liquid Filling Machine Perfume Bottle 100ml 1
