SUS304 Flat Bottle Labeling Machine

Product Description



Description:



Self-adhesive labeling machine is a new generation of series equipment, which is

specially designed and manufactured according to the process and technical requirements of automatic labeling machine. It can make the sticker on the bottle surface smooth and beautiful. The labeling process is stable and reliable, and the labeling position fully meets the ideal requirements.

Self-adhesive labeling machine is an electromechanical integration product with simple and reasonable structure. The machine can automatically roll the self-adhesive paper flat on the bottle body. In the event of a bottle shortage,the machine's control system can ensure that the label paper is not sent out, effectively preventing the waste of the label paper, and according to the bottle

and the label The specifications and characteristics of the production capacity are continuously adjusted.

The labeling machine has strong adaptability to bottles.For plastic bottles of various specifications such as food, medicine,cosmetics, etc., whether it is a round bottle or a flat bottle, self-adhesive labeling, it can be attached to the bottle body satisfactory labeling.





Main Features

1 the sensor detect the product,transmit the signal to labeling control system;

2 after the signal has been processed by the PLC,a label is send out at an appropriate time and attach on a desired position of

the container;

3 the container go through the press plate unit,the press wheel lead the rotation of container,the label is pressed to fit

smoothly, the labeling operation is finished.





Function

It is especially suitable for rigid and soft packing material's automatic plane labeling of medicalments, daily chemicals

food and so on.



Major features and performance

- The machine are adopted the touching display operation, easy and intuitive, fully function.

- Adopted Siemens control system, make machine more stable reliable in operation and long working time.

- Adopt flat-belt convey, stable,reliable, labeling precision is more accurately. Whole machine all compose by stainless

steel and aluminium profile, well-formed.



Fittings Selection

Transparent label sensor.Synchronous hot coding printer, thermal transfer machine, ink jet printing machine



Application:



Specifications:





Production	50-130bottle/min
Label Specifications	Glassine paper, adhesive sticker opaque label
Labeling accuracy	±1mm (subject to the roughness of the plane)
The application of label	Object customizing
The application of label	Height 20-70mm Length 25-120mm
The inner diameter of label	Roll 76mm
The outer diameter of label	Roll 350mm
Driving mode	Servo motor
Power of motor	500w
Voltage	AC 220V 50/60Hz Single phase
Overall dimension	2200×1000×1800mm





After Sales Service

The above machine which we supply it to you, we can give you one years after sales warranty, we can also send our engineer to you factory to install this equipment and train your staff, but the Buyer should pay the round air ticket cost and arrange the hotel accommodation as well as the means for Seller’s engineer. We will send some free set of spare parts for you change it.

Payment terms:

30% deposit by T/T before production, 70% balance should be paid by T/T before shipment. but we also accept L/C.

Package:

Standard wooden Case Packing

Shipment terms:

We usually take FOB, but we can also accept EXW,CIF,CNF
