GD8 200B Rotary Liquid Filling Machine Doypack 380V
  • GD8 200B Rotary Liquid Filling Machine Doypack 380V
  • GD8 200B Rotary Liquid Filling Machine Doypack 380V
  • GD8 200B Rotary Liquid Filling Machine Doypack 380V

GD8 200B Rotary Liquid Filling Machine Doypack 380V

Place of Origin CHINA
Brand Name GD8-200B
Certification CE
Model Number GD8-200B
Product Details
Type::
Packing Machine
Application:
Food,daily Chemical Etc
Automatic Grade::
Automatic
Dimension(L*W*H)::
2000*1200*2400MM
Additional Function:
Hanging Hole,special Shape
Bag Shape::
Zipper Bag/doypack
High Light:

GD8 200B rotary liquid filling machine

,

380V rotary liquid filling machine

,

380V doypack filling machine

Payment & Shipping Terms
Minimum Order Quantity
25
Price
1000USD
Packaging Details
Wooden Case
Delivery Time
25
Payment Terms
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability
25
Product Description



Rotary Liquid Full Automated Packaging Machine for Microwave Popcorn





Performance and features :



, Full automatic 8-staion intermittent rotay performed bags dispensing, opening and closing machine combines with automatic combination weigh scale filler, overhaed work platform and Z-elevator bulk feeder.
2, Safety guard protected for high speed and consistent production.
3, Heavy duty components and parts are selected for machine durability.
4, Hygienic construction and easy cleaning. Operator friendly design touch-screen control system.
5, Versatile in design, easy to link up with other down stream packaging equipment, such as liquid filler, powder filller, multiheads weigher, metal detector, checkweighter, case sealer etc.
6, Innovative and practical solution at reasonable costs.
7, Dust control and extractor system on special request.

Applications for this kind of packaging machines
Liquid: Rice wine, soy sauce, ricevinegar, fruit juice, beverages, milk detergent and so on



Typical Flow Chart
1, Giving bag
2, Hot Foil Coding
3, Bags Opening
4, Fill one consolidate
5, Fill two
6, Heat sealing one
7, Heat sealing two
8, Forming and output product



Technical parameters​ :



Pouch material Laminated film PE PP etc.
Pouch pattern Stand-up,flat
Pouch size W:100-210mm L:100-350mm
(could be customized to your measure)
Filling range 10-1000g (could be customized to your measure)
Speed 10-60pouches/min(The speed depends on the product status and filling weight))
Voltage 380V 3phase 50HZ/60HZ
Compress air 0.6m 3 /min ( Supplied by user)







GD8 200B Rotary Liquid Filling Machine Doypack 380V 0

GD8 200B Rotary Liquid Filling Machine Doypack 380V 1
