Powder Pouch Vertical Automatic Packing Machine 12ml Filling
  • Powder Pouch Vertical Automatic Packing Machine 12ml Filling

Powder Pouch Vertical Automatic Packing Machine 12ml Filling

Place of Origin China
Brand Name LTPM China
Certification CE, GMP
Model Number LTDX
Product Details
Bag Size Of Inner Bag:
L:50-60mm W:30-80mm
Item:
LTDX-115
Bag Size Of Outer Bag:
L:60-120MM W:70-90MM
Capacity:
20-40bags/min
Filling Range:
2-12ml
Power:
220V,50HZ,3.35KW
Weight:
700kg
Dimension:
1200*850*1900mm L*W*H
High Light:

40bags/Min Vertical Automatic Packing Machine

,

12ml Filling Automatic Packing Machine

,

SS304 Automatic Packing Machine

Payment & Shipping Terms
Minimum Order Quantity
1set
Price
Negotiation
Packaging Details
Export standard wooden case
Delivery Time
25days
Payment Terms
L/C, T/T
Supply Ability
25sets/month
Product Description

Integrated automation from bag picking, bag opening, weighing, filling ,vacuuming,sealing,counting and product conveying.This machine is electronic drive.It can reduce noise . And easy operation .Adopt microcomputer control system and touch screen .

Can choose vacuum or no vacuum, can choose inner bag or without inner bag



Bag style

Tea bag with string and tag, bag material is Heat-sealable Filter paper.



Feature

2. PLC control system combined with touch screen, can easily set can change the packing parameters. Daily production output and self-diagnostic machine error can be viewed directly from the screen.

3. Photocell sensor x 2pcs equipped for tracking the colormark designed on the bag material, so make sure the logo designing at same position on each bag.

4. 304 Stainless steel contact part & machine shell.

5. Machine will stop automatically if it is out of film.

6. Fine packaging performance, stable, low noise, clear sealing texture and strong sealing performance .

7. Straight line easy tearing cut & Emboss code as FREE options.



Powder Pouch Vertical Automatic Packing Machine 12ml Filling 0



Specifications:





Item LTDX-115
Bag size of inner bag L:50-60mm W:30-80mm
Bag size of outer bag L:60-120MM W:70-90MM
Capacity 20-40bags/min
Filling range 2-12ml
power 220V,50HZ,3.35KW
Weight 700kg
Dimension 1200*850*1900mm L*W*H
