100ml Ampoule Filling Sealing Machine Plastic Packing PVC
  • 100ml Ampoule Filling Sealing Machine Plastic Packing PVC
  • 100ml Ampoule Filling Sealing Machine Plastic Packing PVC
  • 100ml Ampoule Filling Sealing Machine Plastic Packing PVC
  • 100ml Ampoule Filling Sealing Machine Plastic Packing PVC

100ml Ampoule Filling Sealing Machine Plastic Packing PVC

Place of Origin Zhejiang,China
Brand Name LTPM CHINA
Certification CE
Model Number DPT-Series
Product Details
Max Forming Depth:
12mm*2
Cutting Frequency:
0-25 Times/min, 125 Ampoule/min (10ml/ampoule)
Packaging Material:
PVC/PE (0.2-0.4)*240mm
Capacity Volume:
1-100ml/ampoule
Total Power:
8.5kw
Voltage:
220V-380V/50HZ
Weight:
1200kgs
Dimension:
3200×850×2000 Mm
High Light:

PVC Ampoule Filling Sealing Machine

,

100ml Ampoule Filling Sealing Machine

,

PVC plastic packing machine

Payment & Shipping Terms
Minimum Order Quantity
1 Set/Sets
Price
Negotiable
Packaging Details
wooden
Delivery Time
30 work days
Payment Terms
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability
15Sets per mouth
Product Description

Product Overview

This liquid filling machine is filled with anti-corrosion peristaltic pumps, easy to clean and change tubes, customized trays. Automatic sensing the bottles,each filling nozzle can be operated and filled separately. In order to prevent dripping, the nozzle adopts a unidirectional plastic unidirectional discharge nozzle that prevents backflow.





FEATURES



1.This automatic liquid filling machine is filled with peristaltic pumps.Each pump can be controlled separately.

2.The filling volume is adjusted by set filling time.

3.It is suitable for various trial or small volume product filling,with high filling accuracy.



PRODUCT CONFIGURATION



1.Peristaltic pump:

Adopts peristaltic pump to filling small volume liquid products.

Each pump is is controlled separately.

2.Filling nozzles

The filling nozzles with pneumatic lifting system.

It can be customized into 4/6/8/10 heads model,depends on your requirements.



3.Control panel

Adopts touch screen and speed control knob combination control.



4.

The liquid filling machine need connect air compressor to use.

And the conveyor speed can be adjusted here.



5.Mould

It need customized according to the bottles.

100ml Ampoule Filling Sealing Machine Plastic Packing PVC 0

Specification

Max Forming Depth
12 mm
Cutting Frequency
0-25 times
Filling heads
5 pcs
Packing materials
PVC/PE PET/PE(0.2-0.4)×240mm
Filling Volume
1-50ml
Total Power
8.5kw
Voltage
220V-380V/50HZ
Weight
1200 kgs
Dimension
3200×850×2000 m





Application:

It is a versatile liquid filling equipment, suitable for material packaging in the pharmaceutical,chemical, food, and cosmetic industries; such as: medicinal reagents, liquid medicine, alcohol, Make-up remover, toner, essence, essential oil, etc. various trial or small volume product filling.

100ml Ampoule Filling Sealing Machine Plastic Packing PVC 1
